| Type 類型 |
1A
|
| Max. Contact Rating 最大功率 |
10 W
|
| Max. Switching Voltage 最大開關電壓 |
220 VDC
|
| Max. Switching Current 最大開關電流 |
0.5 A
|
| Min. Breakdown Voltage 最小崩潰電壓 |
250 VDC
|
| Max. Carry Current 最大負載電流 |
1.2A
|
Max. Initial Contact Resistance 最大接觸電阻
Do not include the wire 不含線材 |
100 mΩ
|
| Temperature Rating 溫度範圍 |
-10 ~ +80 ℃
|
| Float Ball Material 浮球材質 |
PP
|
| Float Body Material 本體材質 |
PP+GF
|
| Screw Nut Material 螺母材質 |
ABS
|
| E-Ring Material 檔片材質 |
PP
|
|
|
|
|
