Type 類型 |
2A1
|
2A2
|
Max. Contact Rating 最大功率 |
50 W
|
Max. Switching Voltage 最大開關電壓 |
220 VDC
|
Max. Switching Current 最大開關電流 |
1.5 A
|
Min. Breakdown Voltage 最小崩潰電壓 |
300 VDC
|
Max. Carry Current 最大負載電流 |
3.0 A
|
Max. Initial Contact Resistance 最大接觸電阻
Do not include the wire 不含線材 |
100m Ω
|
Temperature Rating 溫度範圍 |
-30 ~ +180 ℃
|
Float Ball Material 浮球材質 |
SUS304
|
Float Body Material 本體材質 |
SUS304
|
Screw Nut Material 螺母材質 |
SUS304
|
E-Ring Material 檔片材質 |
SUS304
|
|
|
|
|
